B65684A0234A027
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite PM Core (62x49mm) N27 AL=234nH 3%
PDF
/
Inventory: 9913
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Supplier Device Package PM 62 x 49
Material N27
Technical
Tolerance 3%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type PM
Effective Area (Ae) mm2 570
Effective Length (le) mm 109
Effective Magnetic Volume (Ve) mm3 62000
Core Factor (ΣI/A) mm1 0.191
Initial Permeability (μi) 2000
Minimum Core Cross Section (Amin) mm2 470
Dimensions
Diameter 62.00mm
Height 24.50mm
Compliance
RoHS Status ROHS3 Compliant
