B65671T0800A048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories P 26X16 N48 800 +3%- 3%
PDF
/
Inventory: 2688
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Supplier Device Package P 26 x 16
Material N48
Technical
Published 2013
Series B65671
Tolerance ±3%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type P (Pot Core)
Gap Gapped
Effective Area (Ae) mm2 93
Effective Length (le) mm 37.2
Effective Magnetic Volume (Ve) mm3 3460
Core Factor (ΣI/A) mm1 0.4
Minimum Core Cross Section (Amin) mm2 76.5
Inductance Factor (Al) 800nH
Effective Permeability (μe) 255
Dimensions
Diameter 26.00mm
Height 8.15mm
Compliance
RoHS Status ROHS3 Compliant
