B65671T0250G048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories P 26X16 N482 50 +2% -2%
PDF
/
Inventory: 930
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Inductance 250 nH
Part Status Active
Tolerance ±3%
Series B65671
Effective Permeability (μe) 80
Minimum Core Cross Section (Amin) mm2 76.5
Core Factor (ΣI/A) mm1 0.4
Effective Magnetic Volume (Ve) mm3 3460
Effective Length (le) mm 37.2
Effective Area (Ae) mm2 93
Gap Gapped
Core Type P (Pot Core)
Finish Uncoated
Physical
Material N48
Supplier Device Package P 26 x 16
Supply Chain
Factory Lead Time 24 Weeks
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 8.15mm
Diameter 26.00mm
