B65671D1000J048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories P 26X16 N48 1000 +5% -5%
PDF
/
Buying Options
Total Price: USD $5.92
Unit Price: USD $5.9224
≥1 USD $5.9224
≥10 USD $5.04328
≥100 USD $3.837152
≥500 USD $3.72768
≥1000 USD $3.289088
≥3000 USD $3.069818
Inventory: 400
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Physical
Supplier Device Package P 26 x 16
Material N48
Technical
Published 2013
Series B65671
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type P (Pot Core)
Gap Gapped
Effective Area (Ae) mm2 93
Effective Length (le) mm 37.2
Effective Magnetic Volume (Ve) mm3 3460
Core Factor (ΣI/A) mm1 0.4
Minimum Core Cross Section (Amin) mm2 76.5
Inductance Factor (Al) 1μH
Effective Permeability (μe) 318
Dimensions
Diameter 26.00mm
Height 8.15mm
Compliance
RoHS Status ROHS3 Compliant
