B65671D0400A048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories P 26X16 N48 400 +3% -3%
PDF
/
Buying Options
Total Price: USD $4.67
Unit Price: USD $4.6728
≥1 USD $4.6728
≥10 USD $3.97848
≥100 USD $3.045504
Inventory: 659
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 24 Weeks
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Physical
Supplier Device Package P 26 x 16
Material N48
Technical
Published 2013
Series B65671
Tolerance ±3%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Depth 16.3mm
Finish Uncoated
Core Type P (Pot Core)
Gap Gapped
Effective Area (Ae) mm2 93
Effective Length (le) mm 37.2
Effective Magnetic Volume (Ve) mm3 3460
Core Factor (ΣI/A) mm1 0.4
Minimum Core Cross Section (Amin) mm2 76.5
Inductance Factor (Al) 400nH
Effective Permeability (μe) 127
Dimensions
Diameter 26.00mm
Height 8.15mm
Compliance
RoHS Status ROHS3 Compliant
