B65661T0630A048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite P Core (22x13mm) N48 AL=630nH 3%
PDF
/
Inventory: 6097
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 6.80mm
Diameter 22.00mm
Technical
Effective Permeability (μe) 251
Inductance Factor (Al) 630nH
Core Factor (ΣI/A) mm1 0.5
Effective Magnetic Volume (Ve) mm3 1990
Effective Length (le) mm 31.6
Effective Area (Ae) mm2 63
Gap Gapped
Core Type P (Pot Core)
Finish Uncoated
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±3%
Series B65661
Published 2013
Physical
Material N48
Supplier Device Package P 22 x 13
Supply Chain
Factory Lead Time 8 Weeks
