B65661D1250K048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories P 22X13 N48 1250 +10%-10%
PDF
/
Inventory: 1341
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 6.80mm
Diameter 22.00mm
Technical
Effective Permeability (μe) 499
Initial Permeability (μi) 2300
Core Factor (ΣI/A) mm1 0.5
Effective Magnetic Volume (Ve) mm3 1990
Effective Length (le) mm 31.6
Effective Area (Ae) mm2 63
Gap Gapped
Finish Uncoated
Inductance 1.25 μH
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Series B65661
Published 2013
Physical
Weight 13.999987g
Material N48
Supplier Device Package P 22 x 13
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 12 Weeks
