B65661D0160A033
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite P Core (22x13mm) M33 AL=160nH 3%
PDF
/
Inventory: 4442
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Supplier Device Package P 22 x 13
Material M33
Technical
Published 2013
Series B65661
Tolerance 3%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Effective Area (Ae) mm2 63
Effective Length (le) mm 31.6
Effective Magnetic Volume (Ve) mm3 1990
Core Factor (ΣI/A) mm1 0.5
Initial Permeability (μi) 750
Dimensions
Diameter 22.00mm
Height 6.80mm
Compliance
RoHS Status ROHS3 Compliant
