B65541T0040A033
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite P Core (14x8mm) M33 AL=40nH 3%
PDF
/
Inventory: 3414
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 47 Weeks
Physical
Supplier Device Package P 14 x 8
Material M33
Technical
Published 2013
Series B65541
Tolerance 3%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Inductance 40 nH
Outside Diameter 14.3 mm
Finish Uncoated
Effective Area (Ae) mm2 25
Effective Length (le) mm 20
Effective Magnetic Volume (Ve) mm3 500
Core Factor (ΣI/A) mm1 0.8
Initial Permeability (μi) 750
Dimensions
Diameter 14.30mm
Height 4.25mm
Diameter - Inside 11.6 mm
Compliance
RoHS Status ROHS3 Compliant
