B65541D0400A048
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Cores & Accessories P 14X8 N48 400 +3%-3%
PDF
/
Buying Options
Total Price: USD $2.16
Unit Price: USD $2.156
≥1 USD $2.156
≥10 USD $1.8612
≥100 USD $1.414336
≥500 USD $1.340064
≥1000 USD $1.191168
≥3000 USD $1.11672
Inventory: 1564
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 29 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Supplier Device Package P 14 x 8
Material N48
Weight 3.500004g
Technical
Published 2013
Series B65541
Tolerance ±3%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Depth 8.5mm
Inductance 250 nH
Outside Diameter 14.3 mm
Finish Uncoated
Core Type P (Pot Core)
Gap Gapped
Effective Area (Ae) mm2 25
Effective Length (le) mm 20
Effective Magnetic Volume (Ve) mm3 500
Core Factor (ΣI/A) mm1 0.8
Inductance Factor (Al) 400nH
Effective Permeability (μe) 255
Dimensions
Diameter 14.30mm
Height 4.25mm
Diameter - Inside 11.6 mm
Compliance
RoHS Status ROHS3 Compliant
