B65531D0063A033

TDK Electronics Inc.
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description Ferrite Core P Core 6.6mm 11.3mm General Application
PDF
/
Buying Options
Total Price: USD $2.17
Unit Price: USD $2.1736
≥1 USD $2.1736
≥10 USD $1.87176
≥100 USD $1.422432
≥500 USD $1.347632
≥1000 USD $1.197856
≥3000 USD $1.123021
Inventory: 1008
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 24 Weeks

Physical

Supplier Device Package P 11 x 7
Material M33

Technical

Published 2013
Series B65531
Tolerance ±3%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type P (Pot Core)
Gap Gapped
Effective Area (Ae) mm2 15.9
Effective Length (le) mm 15.9
Effective Magnetic Volume (Ve) mm3 253
Core Factor (ΣI/A) mm1 1
Initial Permeability (μi) 750
Inductance Factor (Al) 63nH
Effective Permeability (μe) 50

Dimensions

Diameter 11.30mm
Height 3.30mm

Compliance

RoHS Status ROHS3 Compliant
