B65531D0025A001

TDK Electronics Inc.
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description Ferrite Core P Core 6.6mm 11.3mm General Application
PDF
/
Inventory: 8898
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 24 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)

Physical

Supplier Device Package P 11 x 7
Material K1

Technical

Packaging Bulk
Published 2013
Series B65531
Tolerance ±3%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Depth 6.6mm
Inductance 25 nH
Outside Diameter 11.3 mm
Finish Uncoated
Core Type P (Pot Core)
Gap Gapped
Effective Length (le) mm 15.9
Effective Magnetic Volume (Ve) mm3 253
Core Factor (ΣI/A) mm1 1
Initial Permeability (μi) 80
Effective Permeability (μe) 20

Dimensions

Diameter 11.30mm
Height 3.30mm
Diameter - Inside 9.4 mm

Compliance

RoHS Status ROHS3 Compliant
