B65525J0063A045

TDK Electronics Inc.
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description Ferrite ER Core (11x5mm) N45 AL=63nH 3%
PDF
/
Inventory: 5271
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 24 Weeks

Physical

Supplier Device Package ER 11 x 5
Material N45

Technical

Series B65525
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type ER
Effective Area (Ae) mm2 12.4
Effective Length (le) mm 14.1
Effective Magnetic Volume (Ve) mm3 174
Core Factor (ΣI/A) mm1 1.1
Initial Permeability (μi) 3800
Minimum Core Cross Section (Amin) mm2 10.3

Dimensions

Height 2.50mm
Length 11.00mm
Width 6.00mm

Compliance

RoHS Status ROHS3 Compliant
