B65513J0200D097

TDK Electronics Inc.
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description FERRITE CORE
PDF
/
Inventory: 5633
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 24 Weeks

Physical

Supplier Device Package ER 14.5 x 6
Material N97

Technical

Published 2013
Series B65513
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type ER
Effective Area (Ae) mm2 17.6
Effective Length (le) mm 19
Effective Magnetic Volume (Ve) mm3 334
Core Factor (ΣI/A) mm1 1.08
Initial Permeability (μi) 2300
Minimum Core Cross Section (Amin) mm2 17.3

Dimensions

Height 2.95mm
Length 14.50mm
Width 6.70mm

Compliance

RoHS Status ROHS3 Compliant
