B64290A0084X065
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Toroids / Ferrite Rings 102X66X15 T65 TOROID
PDF
/
Inventory: 6743
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 15.00mm
Diameter 102.00mm
Technical
Inductance Factor (Al) 6.5μH
Initial Permeability (μi) 5000
Core Factor (ΣI/A) mm1 0.96
Effective Magnetic Volume (Ve) mm3 68220
Effective Length (le) mm 255.3
Effective Area (Ae) mm2 267.2
Gap Ungapped
Core Type Toroid
Finish Uncoated
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Series B64290
Published 2013
Physical
Material T65
Supplier Device Package R 102 x 65.8 x 15
Supply Chain
Factory Lead Time 24 Weeks
