B64290A0045X035
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Toroids / Ferrite Rings 16X9.6X6.3 T35 TOROID
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.5896
≥1 USD $0.5896
≥10 USD $0.5324
≥100 USD $0.394592
≥500 USD $0.374704
≥1000 USD $0.347248
Inventory: 4822
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 31 Weeks
Physical
Supplier Device Package R 16 x 9.6 x 6.3
Material T35
Technical
Published 2013
Series B64290
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Finish Uncoated
Core Type Toroid
Gap Ungapped
Effective Area (Ae) mm2 19.73
Effective Length (le) mm 38.52
Effective Magnetic Volume (Ve) mm3 760
Core Factor (ΣI/A) mm1 1.95
Initial Permeability (μi) 6000
Inductance Factor (Al) 3.87μH
Dimensions
Diameter 16.00mm
Height 6.30mm
Compliance
RoHS Status ROHS3 Compliant
