B64290A0022X830
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
Ferrite Toroid Ring Core (41.8x26.2x12.5mm) N30 AL=5000nH 30%
PDF
/
Inventory: 5856
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Diameter - Inside 26.2 mm
Height 12.50mm
Diameter 41.80mm
Technical
Inductance Factor (Al) 5μH
Initial Permeability (μi) 4300
Core Factor (ΣI/A) mm1 1.08
Effective Magnetic Volume (Ve) mm3 9862
Effective Length (le) mm 103
Effective Area (Ae) mm2 95.75
Gap Ungapped
Core Type Toroid
Finish Uncoated
Outside Diameter 41.8 mm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±25%
Series B64290
Published 2013
Physical
Material N30
Supplier Device Package R 41.8 x 26.2 x 12.5
Supply Chain
Factory Lead Time 24 Weeks
