B62152A0015X030
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORE 2 HOLE 1.6UH N30
PDF
/
Inventory: 3110
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 27 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Physical
Material N30
Technical
Published 2013
Series B62152
Tolerance ±30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Frequency 250MHz
Finish Uncoated
Core Type Multi-Hole (2)
Gap Ungapped
Effective Area (Ae) mm2 1.2
Effective Length (le) mm 3.7
Effective Magnetic Volume (Ve) mm3 4.5
Core Factor (ΣI/A) mm1 3.22
Initial Permeability (μi) 4300
Inductance Factor (Al) 1.6μH
Dimensions
Height 1.40mm
Length 3.60mm
Width 2.10mm
Diameter - Inside 1.4 mm
Compliance
RoHS Status ROHS3 Compliant
