TX50/30/19-3E65

Ferroxcube
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description FERRITE CORES ROUND
PDF
/
Inventory: 5096
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Dimensions

Height 20.10mm
Diameter 51.25mm

Technical

Effective Permeability (μe) 5200
Core Factor (ΣI/A) mm1 0.65
Effective Magnetic Volume (Ve) mm3 22378
Effective Length (le) mm 120.4
Effective Area (Ae) mm2 186
Gap Ungapped
Core Type Toroid
Finish Epoxy
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±25%
Published 2016

Physical

Supplier Device Package TX 50 x 30 x 19

Supply Chain

Factory Lead Time 8 Weeks
