TX42/26/13-3E12

Ferroxcube
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description FERRITE CORES ROUND
PDF
/
Buying Options
Total Price: USD $6.18
Unit Price: USD $6.1776
≥1 USD $6.1776
≥10 USD $5.25888
≥100 USD $4.001536
≥500 USD $3.887312
≥1000 USD $3.429923
≥3000 USD $3.201255
Inventory: 523
Minimum: 1
-
+

Technical Details

Dimensions

Height 13.50mm
Diameter 43.15mm

Technical

Effective Permeability (μe) 12000
Core Factor (ΣI/A) mm1 1.076
Effective Magnetic Volume (Ve) mm3 9860
Effective Length (le) mm 103
Effective Area (Ae) mm2 95.8
Gap Ungapped
Core Type Toroid
Finish Epoxy
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±30%
Published 2016

Physical

Supplier Device Package TX 42 x 26 x 13

Supply Chain

Factory Lead Time 8 Weeks
