TX29/19/7.6-3E65
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORES ROUND
PDF
/
Inventory: 7985
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Height 6.55mm
Diameter 16.25mm
Technical
Effective Permeability (μe) 5200
Core Factor (ΣI/A) mm1 2.06
Effective Magnetic Volume (Ve) mm3 2600
Effective Length (le) mm 73.2
Effective Area (Ae) mm2 35.5
Gap Ungapped
Core Type Toroid
Finish Epoxy
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±25%
Physical
Supplier Device Package TX 29 x 19 x 7.6
Supply Chain
Factory Lead Time 8 Weeks
