TX26/15/20-3E65

Ferroxcube
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description FERRITE CORES ROUND
PDF
/
Inventory: 4095
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Dimensions

Height 21.00mm
Diameter 26.95mm

Technical

Effective Permeability (μe) 5200
Core Factor (ΣI/A) mm1 0.538
Effective Magnetic Volume (Ve) mm3 6720
Effective Length (le) mm 60.1
Effective Area (Ae) mm2 112
Gap Ungapped
Core Type Toroid
Finish Epoxy
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±25%
Published 2016

Physical

Supplier Device Package TX 26 x 15 x 20

Supply Chain

Factory Lead Time 8 Weeks
