TX26/15/10-3E27-M7
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORES ROUND
PDF
/
Inventory: 6849
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Supplier Device Package TX 26 x 15 x 10
Material 3E27
Technical
Published 2016
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Epoxy
Core Type Toroid
Gap Ungapped
Effective Area (Ae) mm2 55.9
Effective Length (le) mm 60.1
Effective Magnetic Volume (Ve) mm3 3360
Core Factor (ΣI/A) mm1 1.08
Effective Permeability (μe) 7000
Dimensions
Diameter 26.95mm
Height 10.90mm
