TX25/15/13-3E6
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORES ROUND
PDF
/
Buying Options
Total Price: USD $1.99
Unit Price: USD $1.9888
≥1 USD $1.9888
≥10 USD $1.71512
≥100 USD $1.303456
≥500 USD $1.234816
≥1000 USD $1.028975
≥3000 USD $0.96037
Inventory: 531
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Supplier Device Package TX 25 x 15 x 13
Technical
Published 2016
Tolerance ±30%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Epoxy
Core Type Toroid
Gap Ungapped
Effective Area (Ae) mm2 62.1
Effective Length (le) mm 60.1
Effective Magnetic Volume (Ve) mm3 3740
Core Factor (ΣI/A) mm1 0.97
Effective Permeability (μe) 10000
Dimensions
Diameter 25.95mm
Height 13.70mm
