TX20/10/7-3E10-M
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
TX 20x 10x 7 Toroid Epoxy Ferrite Core 20.25mm ±30%
PDF
/
Buying Options
Total Price: USD $1.05
Unit Price: USD $1.053699
≥1 USD $1.053699
≥10 USD $0.994046
≥100 USD $0.937788
≥500 USD $0.884704
≥1000 USD $0.834635
Inventory: 1159
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Supplier Device Package TX 20 x 10 x 7
Technical
Published 2016
Tolerance ±30%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Epoxy
Core Type Toroid
Gap Ungapped
Effective Area (Ae) mm2 33.6
Effective Length (le) mm 43.6
Effective Magnetic Volume (Ve) mm3 1465
Core Factor (ΣI/A) mm1 1.3
Dimensions
Diameter 20.25mm
Height 7.40mm
