TX16/9.1/4.7-3E65
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORES ROUND
PDF
/
Buying Options
Total Price: USD $0.8
Unit Price: USD $0.8008
≥1 USD $0.8008
≥10 USD $0.7216
≥100 USD $0.534688
≥500 USD $0.50776
≥1000 USD $0.454344
≥3000 USD $0.42761
Inventory: 1082
Minimum: 1
-
+
Technical Details
Dimensions
Height 4.95mm
Diameter 16.13mm
Technical
Initial Permeability (μi) 10500
Core Factor (ΣI/A) mm1 2.53
Effective Magnetic Volume (Ve) mm3 548
Effective Length (le) mm 37.2
Effective Area (Ae) mm2 14.7
Gap Ungapped
Core Type Toroid
Finish Epoxy
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±30%
Physical
Supplier Device Package TX 16 x 9.1 x 4.7
Supply Chain
Factory Lead Time 8 Weeks
