TX107/65/18-3C94

Ferroxcube
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description FERRITE CORES ROUND
PDF
/
Buying Options
Total Price: USD $43.2
Unit Price: USD $43.1992
≥1 USD $43.1992
≥10 USD $38.40173
≥100 USD $31.681223
≥500 USD $30.72124
≥1000 USD $26.88107
≥3000 USD $24.960954
Inventory: 51
Minimum: 1
-
+

Technical Details

Dimensions

Height 18.30mm
Diameter 107.40mm

Technical

Core Factor (ΣI/A) mm1 0.7
Effective Magnetic Volume (Ve) mm3 96000
Effective Length (le) mm 259
Effective Area (Ae) mm2 370
Gap Ungapped
Core Type Toroid
Finish Epoxy
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±25%
Published 2016

Physical

Material 3C94
Supplier Device Package TX 107 x 65 x 18

Supply Chain

Factory Lead Time 8 Weeks
