TX102/66/15-3C94
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORES ROUND
PDF
/
Buying Options
Total Price: USD $37
Unit Price: USD $37.002791
≥1 USD $37.002791
≥10 USD $34.908297
≥100 USD $32.932354
≥500 USD $31.068258
≥1000 USD $29.309674
Inventory: 950
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Material 3C94
Technical
Published 2016
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Epoxy
Core Type Toroid
Gap Ungapped
Effective Area (Ae) mm2 267
Effective Length (le) mm 255
Effective Magnetic Volume (Ve) mm3 68200
Core Factor (ΣI/A) mm1 0.956
Initial Permeability (μi) 4300
Dimensions
Diameter 102.40mm
Height 15.30mm
