RM8/I-3C91
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Inventory: 5402
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 11.00mm
Length 23.20mm
Height 16.40mm
Technical
Effective Permeability (μe) 1990
Minimum Core Cross Section (Amin) mm2 55.4
Core Factor (ΣI/A) mm1 0.604
Effective Magnetic Volume (Ve) mm3 2440
Effective Length (le) mm 38.4
Effective Area (Ae) mm2 63
Gap Ungapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±25%
Physical
Material 3C91
Supplier Device Package RM 8
Supply Chain
Factory Lead Time 7 Weeks
