RM8/I-3C91-A160

Ferroxcube
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description RM CORES 2PC SET
PDF
/
Inventory: 9055
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 7 Weeks

Physical

Supplier Device Package RM 8
Material 3C91

Technical

Tolerance ±3%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type RM
Gap Gapped
Effective Area (Ae) mm2 63
Effective Length (le) mm 38.4
Effective Magnetic Volume (Ve) mm3 2440
Core Factor (ΣI/A) mm1 0.44
Minimum Core Cross Section (Amin) mm2 55.4
Inductance Factor (Al) 160nH
Effective Permeability (μe) 78

Dimensions

Height 9.40mm
Length 23.20mm
Width 11.00mm

Compliance

RoHS Status ROHS3 Compliant
