RM8/I-3C90-A630
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Inventory: 2120
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package RM 8
Material 3C90
Technical
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type RM
Gap Gapped
Effective Area (Ae) mm2 63
Effective Length (le) mm 38.4
Effective Magnetic Volume (Ve) mm3 2440
Core Factor (ΣI/A) mm1 0.44
Minimum Core Cross Section (Amin) mm2 55.4
Inductance Factor (Al) 630nH
Effective Permeability (μe) 310
Dimensions
Height 9.40mm
Length 23.20mm
Width 11.00mm
Compliance
RoHS Status ROHS3 Compliant
