RM6S/ILP-3F36-A100

Ferroxcube
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description RM CORES 2PC SET
PDF
/
Inventory: 1424
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 8.20mm
Length 17.90mm
Height 12.40mm

Technical

Effective Permeability (μe) 46
Inductance Factor (Al) 100nH
Minimum Core Cross Section (Amin) mm2 31.2
Core Factor (ΣI/A) mm1 0.784
Effective Magnetic Volume (Ve) mm3 820
Effective Length (le) mm 21.8
Effective Area (Ae) mm2 37.5
Gap Gapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±3%

Physical

Material 3F36
Supplier Device Package RM 6

Supply Chain

Factory Lead Time 7 Weeks
