RM6S/I-3F46-A160

Ferroxcube
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description RM CORES 2PC SET
PDF
/
Inventory: 8176
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 7 Weeks

Physical

Supplier Device Package RM 6
Material 3F46

Technical

Tolerance ±3%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type RM
Gap Gapped
Effective Area (Ae) mm2 37
Effective Length (le) mm 29.2
Effective Magnetic Volume (Ve) mm3 1090
Core Factor (ΣI/A) mm1 0.784
Minimum Core Cross Section (Amin) mm2 31.2
Inductance Factor (Al) 160nH
Effective Permeability (μe) 100

Dimensions

Height 12.40mm
Length 17.90mm
Width 8.20mm

Compliance

RoHS Status ROHS3 Compliant
