RM6S/I-3F46
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Inventory: 6179
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 8.20mm
Length 17.90mm
Height 12.40mm
Technical
Minimum Core Cross Section (Amin) mm2 31.2
Core Factor (ΣI/A) mm1 0.784
Effective Magnetic Volume (Ve) mm3 1090
Effective Length (le) mm 29.2
Effective Area (Ae) mm2 37
Gap Ungapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±25%
Physical
Material 3F46
Supplier Device Package RM 6
Supply Chain
Factory Lead Time 7 Weeks
