RM5/I-3C96-A160

Ferroxcube
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description RM CORES 2PC SET
PDF
/
Inventory: 7591
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 12.30mm
Length 14.90mm
Height 10.40mm

Technical

Effective Permeability (μe) 120
Inductance Factor (Al) 160nH
Minimum Core Cross Section (Amin) mm2 18.1
Core Factor (ΣI/A) mm1 0.935
Effective Magnetic Volume (Ve) mm3 574
Effective Length (le) mm 23.2
Effective Area (Ae) mm2 24.8
Gap Gapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±3%

Physical

Material 3C96
Supplier Device Package RM 5

Supply Chain

Factory Lead Time 7 Weeks
