RM4/ILP-3F36
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Inventory: 6151
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 9.80mm
Length 11.00mm
Height 7.80mm
Technical
Minimum Core Cross Section (Amin) mm2 11.3
Core Factor (ΣI/A) mm1 1.19
Effective Magnetic Volume (Ve) mm3 251
Effective Length (le) mm 17.3
Effective Area (Ae) mm2 14.5
Gap Ungapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±25%
Physical
Material 3F36
Supplier Device Package RM 4
Supply Chain
Factory Lead Time 7 Weeks
Alternative Model
