RM14/I-3F4-A630

Ferroxcube
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description RM CORES 2PC SET
PDF
/
Inventory: 2216
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 19.00mm
Length 42.20mm
Height 30.10mm

Technical

Effective Permeability (μe) 180
Inductance Factor (Al) 630nH
Minimum Core Cross Section (Amin) mm2 168
Core Factor (ΣI/A) mm1 0.353
Effective Magnetic Volume (Ve) mm3 13900
Effective Length (le) mm 70
Effective Area (Ae) mm2 198
Gap Gapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±3%

Physical

Material 3F4
Supplier Device Package RM 14

Supply Chain

Factory Lead Time 7 Weeks
