RM14/I-3C96
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Buying Options
Total Price: USD $8.91
Unit Price: USD $8.9056
≥1 USD $8.9056
≥10 USD $7.58824
≥100 USD $5.60846
≥500 USD $4.948574
Inventory: 279
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package RM 14
Material 3C96
Technical
Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type RM
Gap Ungapped
Effective Area (Ae) mm2 198
Effective Length (le) mm 70
Effective Magnetic Volume (Ve) mm3 13900
Core Factor (ΣI/A) mm1 0.353
Minimum Core Cross Section (Amin) mm2 168
Dimensions
Height 30.10mm
Length 42.20mm
Width 19.00mm
Compliance
RoHS Status ROHS3 Compliant
