RM12/ILP-3F36-A400
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Inventory: 5222
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package RM 12
Material 3F36
Technical
Tolerance ±3%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type RM
Gap Gapped
Effective Area (Ae) mm2 148
Effective Length (le) mm 42
Effective Magnetic Volume (Ve) mm3 6200
Core Factor (ΣI/A) mm1 0.388
Minimum Core Cross Section (Amin) mm2 125
Inductance Factor (Al) 400nH
Effective Permeability (μe) 90
Dimensions
Height 24.50mm
Length 37.40mm
Width 16.10mm
Compliance
RoHS Status ROHS3 Compliant
