RM12/I-3C97
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Inventory: 7334
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 16.10mm
Length 37.40mm
Height 24.50mm
Technical
Effective Permeability (μe) 2090
Minimum Core Cross Section (Amin) mm2 125
Core Factor (ΣI/A) mm1 0.388
Effective Magnetic Volume (Ve) mm3 8340
Effective Length (le) mm 56.6
Effective Area (Ae) mm2 146
Gap Ungapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±25%
Physical
Material 3C97
Supplier Device Package RM 12
Supply Chain
Factory Lead Time 7 Weeks
