RM10/ILP-3F4

Ferroxcube
RoHS
RoHS RoHS compliant
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description RM CORES 2PC SET
PDF
/
Inventory: 4627
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 7 Weeks

Physical

Supplier Device Package RM 10
Material 3F4

Technical

Tolerance ±25%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type RM
Gap Ungapped
Effective Area (Ae) mm2 99.1
Effective Length (le) mm 33.9
Effective Magnetic Volume (Ve) mm3 3360
Core Factor (ΣI/A) mm1 0.34
Minimum Core Cross Section (Amin) mm2 89.1
Effective Permeability (μe) 817

Dimensions

Height 13.00mm
Length 28.50mm
Width 13.50mm

Compliance

RoHS Status ROHS3 Compliant
