RM10/I-3C97-A400
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Inventory: 5419
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package RM 10 x 1
Material 3C97
Technical
Tolerance ±3%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Finish Uncoated
Core Type RM
Gap Gapped
Effective Area (Ae) mm2 96.6
Effective Length (le) mm 44.6
Effective Magnetic Volume (Ve) mm3 4310
Core Factor (ΣI/A) mm1 0.462
Minimum Core Cross Section (Amin) mm2 89.1
Inductance Factor (Al) 400nH
Effective Permeability (μe) 147
Dimensions
Height 18.60mm
Length 28.50mm
Width 13.50mm
Compliance
RoHS Status ROHS3 Compliant
