RM10/I-3C95-A250
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
RM CORES 2PC SET
PDF
/
Inventory: 4267
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 13.50mm
Length 28.50mm
Height 18.60mm
Technical
Effective Permeability (μe) 92
Inductance Factor (Al) 250nH
Minimum Core Cross Section (Amin) mm2 89.1
Core Factor (ΣI/A) mm1 0.462
Effective Magnetic Volume (Ve) mm3 4310
Effective Length (le) mm 44.6
Effective Area (Ae) mm2 96.6
Gap Gapped
Core Type RM
Finish Uncoated
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±3%
Physical
Material 3C95
Supplier Device Package RM 10 x 1
Supply Chain
Factory Lead Time 8 Weeks
