PQ35/20-3C94
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
PQ CORES 2PC SET
PDF
/
Inventory: 6192
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 26.00mm
Length 36.00mm
Height 20.00mm
Technical
Effective Permeability (μe) 1790
Minimum Core Cross Section (Amin) mm2 163
Core Factor (ΣI/A) mm1 0.291
Effective Magnetic Volume (Ve) mm3 11300
Effective Length (le) mm 57.5
Effective Area (Ae) mm2 197
Gap Ungapped
Core Type PQ
Finish Uncoated
Part Status Active
Tolerance ±25%
Physical
Material 3C94
Supplier Device Package PQ 35 x 20
Supply Chain
Factory Lead Time 7 Weeks
