PQ32/25-3C96
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
PQ CORES 2PC SET
PDF
/
Inventory: 3865
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 22.00mm
Length 33.00mm
Height 25.00mm
Technical
Minimum Core Cross Section (Amin) mm2 143
Core Factor (ΣI/A) mm1 0.383
Effective Magnetic Volume (Ve) mm3 10800
Effective Length (le) mm 64.2
Effective Area (Ae) mm2 168
Gap Ungapped
Core Type PQ
Finish Uncoated
Part Status Active
Tolerance ±25%
Physical
Material 3C96
Supplier Device Package PQ 32 x 25
Supply Chain
Factory Lead Time 7 Weeks
