PQ32/20-3C96
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
PQ CORES 2PC SET
PDF
/
Inventory: 2554
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 22.00mm
Length 33.00mm
Height 20.60mm
Technical
Effective Permeability (μe) 1580
Minimum Core Cross Section (Amin) mm2 142
Core Factor (ΣI/A) mm1 0.331
Effective Magnetic Volume (Ve) mm3 9440
Effective Length (le) mm 55.9
Effective Area (Ae) mm2 169
Gap Ungapped
Core Type PQ
Finish Uncoated
Part Status Active
Tolerance ±25%
Physical
Material 3C96
Supplier Device Package PQ 32 x 20
Supply Chain
Factory Lead Time 7 Weeks
