PQ20/16-3C94
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
PQ CORES 2PC SET
PDF
/
Inventory: 2023
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Supplier Device Package PQ 20 x 16
Material 3C94
Technical
Tolerance ±25%
Part Status Active
Finish Uncoated
Core Type PQ
Gap Ungapped
Effective Area (Ae) mm2 61.9
Effective Length (le) mm 37.6
Effective Magnetic Volume (Ve) mm3 2330
Core Factor (ΣI/A) mm1 0.607
Minimum Core Cross Section (Amin) mm2 59.1
Dimensions
Height 16.20mm
Length 21.30mm
Width 14.00mm
Compliance
RoHS Status ROHS3 Compliant
