P22/13-3F36
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
P CORES 2PC SET
PDF
/
Buying Options
Total Price: USD $3.84
Unit Price: USD $3.8368
≥1 USD $3.8368
≥10 USD $3.26832
≥100 USD $2.486528
≥500 USD $2.415424
≥1000 USD $2.131272
≥3000 USD $1.989187
Inventory: 1869
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 13.40mm
Diameter 22.00mm
Technical
Effective Permeability (μe) 1070
Inductance Factor (Al) 2.7μH
Minimum Core Cross Section (Amin) mm2 50.9
Core Factor (ΣI/A) mm1 0.497
Effective Magnetic Volume (Ve) mm3 2000
Effective Length (le) mm 31.5
Effective Area (Ae) mm2 63.4
Gap Ungapped
Core Type P
Finish Uncoated
Part Status Active
Tolerance ±25%
Physical
Material 3F36
Supplier Device Package P 22 x 13
Supply Chain
Factory Lead Time 7 Weeks
