P18/11-3C81
RoHS
/
Package /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
FERRITE CORE, P, 3C81
PDF
/
Inventory: 1121
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Height 10.60mm
Diameter 18.40mm
Technical
Effective Permeability (μe) 1900
Inductance Factor (Al) 4μH
Minimum Core Cross Section (Amin) mm2 36
Core Factor (ΣI/A) mm1 0.597
Effective Magnetic Volume (Ve) mm3 1120
Effective Length (le) mm 25.8
Effective Area (Ae) mm2 43.3
Gap Ungapped
Core Type P (Pot Core)
Finish Uncoated
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±25%
Published 2005
Physical
Supplier Device Package P 18 x 11
Supply Chain
Factory Lead Time 24 Weeks
