ER9.5/2.5/5-3C92-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Magnetics - Transformer, Inductor Components / Ferrite Cores
Description
PLANAR ER CORES 2PC SET
PDF
/
Inventory: 6698
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 5.00mm
Length 9.50mm
Height 2.45mm
Technical
Effective Permeability (μe) 1000
Minimum Core Cross Section (Amin) mm2 7.6
Core Factor (ΣI/A) mm1 1.67
Effective Magnetic Volume (Ve) mm3 120
Effective Length (le) mm 14.2
Effective Area (Ae) mm2 8.47
Gap Ungapped
Core Type ER
Finish Uncoated
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Tolerance ±25%
Physical
Material 3C92
Supplier Device Package ER 9.5 x 2.5 x 5
Supply Chain
Factory Lead Time 7 Weeks
